JARTON Phoenix VMS Centralized Video Management System
฿590,000.00
มีสินค้า
เหลือ 1 เท่านั้น
SKU
133308
| Technical Specifications | |
| Device Performance | |
| Device management | IPC, NVR, Face recognition terminal, decoder (standard/expanded), network keyboard, cloud devices, alarm control panel and door access control |
| Number of connected cameras per server | 1000 devices or 2000 channels 1000 devices connected via Onvif |
| Number of 3rd-party alarm control panels, access control devices | 30 devices |
| Number of connected face recognition terminals | 128 devices |
| Numbers of online client users | 300 users |
| Numbers of online mobile client users | 64 users |
| Video input bandwidth per server | 512 Mbps |
| Video forwarding bandwidth per server | 384 Mbps |
| Number of recording channels per server | 256 channels @ 512 Mbps |
| View display mode | 1/3/4/5/6/7/8/9/10/13/16/17/25/32/36/64 window display; Corridor format display |
| Decoding Performance | |
| Recording resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/960P/720P/960H/D1/2CIF/CIF/QCIF |
| Decoding capability | 4?4K@30 / 16?1080p@30 / 36?720p@30 / 64?D1 |
| Video compression | Ultra265, H.265, H.264 |
| Built-in decoder | 2 x HDMI and 1 x VGA; HDMI output supports 4K resolution |
| Decoding card (optional) | Max 2 cards supported; HDMI4-C and HDMI6-C |
| HDMI4-C decoding card | 4-ch HDMI outputs, with decoding of 4x4K@60 or 8x4K@30 or 32x1080P@30 or 64x720P@30 |
| HDMI6-C decoding card | 6-ch HDMI outputs, with decoding of 6x4K@60 or 12x4K@30 or 48x1080P@30 or 96x720P@30 |
| Synchronous playback | 24-ch |
| Audio compression | G.711A, G.711? |
| Storage | |
| HDD installation | Support 16HDDs (SATA 3.5”, up to 14TB for each); Hot-swappable HDDs |
| RAID mode | RAID 0/1/5/6/10/50/60 |
| Disk enclosure (optional) | Max 2 disk enclosures supported |
| 1008 SATA disk enclosure | 8xSATA interfaces, up to 14TB storage per interface |
| 1016 SATA disk enclosure | 16xSATA interfaces, up to 14TB storage per interface |
| System | |
| Processor | Intel(R) processor 64-bit high-performance |
| Memory | 4GB DDR3L |
| Operating System | Linux OS, dual-BIOS |
| Data Info | |
| Image processing performance | Receive vehicle or face images: 100 images per second Note: For example, if each device uploads 1 image per second, then 100 devices can be connected; if each device uploads 5 images per second, then 20 devices can be connected |
| Alarm processing capacity | 100 records/s |
| Alarm Records | 200,000 records |
| Operation logs | 200,000 records |
| Face capture records | 3 million records |
| Face alarm records | 3 million records |
| Vehicle pass-through records | 3 million records |
| Structured motor vehicle, non-motor vehicle and pedestrian records | 3 million records |
| Access control entry/exit records | 3 million records |
| Interface | |
| Network | 4 ? 10/100/1000 Mbps Base-T adaptive Ethernet interfaces 2 ? 1000M SFP optical interfaces |
| USB | 4 ? USB3.0 |
| HDMI | 2 ? HDMI |
| VGA | 1 ? VGA |
| Serial | 1 ? RS-232 (RJ45), 1 ? RS-485 (RJ45) |
| Alarm input/output | 24 ? alarm inputs, 8 ? alarm outputs; Audio alarm : Buzzer |
| Power output | 12v DC |
| Expansion | 1 ? eSATA interface, 2 ? miniSAS interfaces, 2 ? decoding cards |
| General | |
| Power supply | Input voltage 100-240 VAC (with power on/off switch); Dual-power redundancy |
| Power consumption | ? 50W (not including HDD), ? 165W (including HDD) |
| Operating temperature | -10?C to 55?C (-14?F to 131?F) |
| Operating humidity | 10% to 90% (non condensing) |
| Weight | ? 10.0 Kg |
| Dimensions (D?W?H) | Height: 3U, support mounting in standard 19” cabinet 477.1 mm ? 481.6 mm ? 130.5 mm (18.8’’?19’’?5.1’’) (including front panel) |
