Technical Specifications | |
Camera | |
Image sensor | 1/2.8”, 2.0 megapixel Progressive scan, CMOS |
Lens | 4.5-148.5 mm, F1.5-4.0, DC Auto-iris Horizontal field of view 56.2?-2.6? Vertical field of view 33.5?-1.4? AF automatic focusing and motorized zoom lens |
DORI distance | Detect : 4.5 mm / 72.9 m 148.5 mm / 2187.9 m Observe : 4.5 mm / 29.2 m 148.5 mm / 875.2 m Recognize : 4.5 mm / 14.6 m 148.5 mm / 437.6 m Identify : 4.5 mm / 7.3 m 148.5 mm / 218.8 m |
Day and night | IR-cut filter with auto switch (ICR) |
Minimum illumination | Color: 0.001 Lux (F1.5, AGC ON) 0 Lux with IR on |
Shutter time | 1 to 1/100000 sec |
IR Illumination | Smart IR, 850nm wavelength Maximum distance up to 150 meters |
Wide dynamic range (WDR) | 120 dB |
Video | |
Maximum resolution | 1920 x 1080 |
Multi-streaming | 3 Streams |
Frame rate | Main Stream 1080P (1920 x 1080), Max 60 fps Sub Stream 1080P (1920 x 1080), Max 60 fps Third Stream D1 (720?576), Max. 60 fps |
Video compression | Ultra 265, H.265, H.264 (Baseline/Main/ High Profile), MJPEG |
Video Bit rate | CBR/VBR, 128 Kbps~16 Mbps |
Audio | |
Audio streaming | Two-way audio |
Audio compression | G.711A, G.711U |
Sampling Rate | 8 kHz |
Suppression | Supported |
Image | |
White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/ Locked/Auto2 |
Digital noise reduction | 2D/3D DNR |
Backlight Compensation (BLC) | On/Off |
Highlight Compensation (HLC) | On/Off |
Image defogging | Digital defog |
Image rotation | Normal/Vertical/Horizontal/180?/ 90?Clockwise/90?Anti-clockwise |
OSD | Up to 8 OSDs |
Privacy Mask | Up to 24 areas |
Region of interest (ROI) | Up to 8 areas |
Motion Detection | Up to 4 areas |
Pan/Tilt/Zoom | |
Pan range | 360? endless |
Pan speed | 0.1?- 240?/s; Preset position: 300?/s |
Tilt range | -15?- 90? auto reverse |
Tilt speed | 0.1?- 80?/s; Preset position: 80?/s |
Zoom | 33x optical zoom, 16x digital zoom |
Number of presets | 1024 presets |
Patrol | Preset patrol, Route patrol, Recorded patrol |
Smart AI Function | |
Behavior detection | Auto-Tracking, Intrusion detection, Cross line detection, Motion detection |
Intelligent identification | Face detection, Object removal, Object left behind |
Statistical analysis | People counting |
Event triggers | Tampering detection, Audio detection |
Network | |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS |
Compatible Integration | ONVIF? Profile G, ONVIF? Profile S and ONVIF? Profile T, API |
Security | IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication |
Interface | |
Network | 1 x RJ45 10/100M Base-TX Ethernet |
Serial port | 1 x RS485 |
Audio input | Impedance 35k?; amplitude 2V [p-p] |
Audio output | impedance 600?; amplitude 2V [p-p] |
Alarm input/output | 2 input, 1 output |
Video output | BNC |
Reset Button | Supported |
General | |
Ingress protection | IP66 |
Impact resistance | - |
Material | Body : Metal Front cover : Plastic |
Edge Storage | Micro SD card up to 256GB ANR (Automatic Network Replenishment |
Operating conditions | -40?C to 65?C (-40?F to 149?F) Humidity: ?95% RH (non-condensing) |
Storage conditions | -40?C to 70?C (-40?F to 158?F) Humidity: ?95% RH (non-condensing) |
Power | Power over Ethernet (PoE; PSE required) DC 12V?10%, max 22 W |
Surge protection | 6 kV |
Dimension | ?220 x 369 mm (?8.7” x 14.5”) |
Net weight | 3.4 kg (7.5 lb) |
