Technical Specifications
Camera
Image sensor 1/2.8”, 2.0 megapixel
Progressive scan, CMOS
Lens 2.7-13.5 mm, F1.2, Fixed iris
Horizontal field of view 107.4
?-33.5?
Vertical field of view 60.2?-13.2?
AF automatic focusing and motorized
zoom lens
DORI distance Detect : 2.7 mm / 41.9 m
13.5 mm / 209.5 m
Observe : 2.7 mm / 16.8 m
13.5 mm / 83.8 m
Recognize : 2.7 mm / 8.4 m
13.5 mm / 41.9 m
Identify : 2.7 mm / 4.2 m
13.5 mm / 20.9 m
Day and night IR-cut filter with auto switch (ICR)
Minimum illumination Color: 0.0005 Lux (F1.2, AGC ON)
0 Lux with IR on
Shutter time 1 to 1/100000 sec
IR Illumination Smart IR, 850nm wavelength
Maximum distance up to 40 meters
Wide dynamic range (WDR) 120 dB
Camera angle adjustment Pan 0? to 360?
Tilt 0? to 90?
Rotation 0? to 360?
Video
Maximum resolution 1920 x 1080
Multi-streaming 3 Streams
Frame rate Main Stream
1080P (1920 x 1080), Max 30 fps
Sub Stream
720P (1280 x 720), Max 30 fps
Third Stream
D1 (720 x 576), Max 30 fps
Video
compression
Ultra 265, H.265, H.264 (Baseline/Main/
High Profile), MJPEG
Video Bit rate CBR/VBR, 128 Kbps~16 Mbps
Audio
Audio streaming Audio in
Audio compression G.711, 8 kHz sampling rate
Suppression Supported

White Balance Auto/Outdoor/Fine Tune/Sodium Lamp/
Locked/Auto2
Digital noise reduction 2D/3D DNR
Backlight Compensation
(BLC)
On/Off
Highlight Compensation
(HLC)
On/Off
Image defogging Digital defog
Image dewarping -
Image rotation Normal/Vertical/Horizontal/180?/
90
?Clockwise/90?Anti-clockwise
including Corridor Format (9:16)
OSD Up to 8 OSDs
Privacy Mask Up to 4 areas
Region of interest (ROI) Up to 8 areas
Motion Detection Up to 4 areas
Network
Protocols IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP,
PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP,
FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP,
QoS
Compatible Integration ONVIF? Profile G, ONVIF? Profile S and
ONVIF? Profile T, API
Security IP address filtering, Access policy,
ARP protection, RTSP authentication,
User authentication
Interface
Network 1 x RJ45 10/100M Base-TX Ethernet
Audio input -
Audio output -
Alarm input/output -
Video output -
Built-in Mic Supported
Reset Button Supported

General
Ingress protection IP67
Impact resistance IK10
Material Metal
Edge Storage Micro SD card up to 256GB
ANR (Automatic Network Replenishment)
NAS (NFS protocol)
Operating conditions -30?C to 60?C (-22?F to 140?F)
Humidity: ?95% RH (non-condensing)
Storage conditions -30?C to 60?C (-22?F to 140?F)
Humidity: ?95% RH (non-condensing)
Power Power over Ethernet (PoE) IEEE 802.3af
DC 12V?25%, max 7 W
Surge protection 6 kV
Dimension ?129 x 110 mm (?5.1” x 4.3”)
Net weight 0.69 kg (1.52 lb)
